| Parameter | Specification |
|---|---|
| Design Standard | API 623, API 600, ASME B16.34 |
| Size Range | 2" – 24" (DN50 – DN600) |
| Pressure Rating | Class 150 – Class 2500 (PN16 – PN420) |
| Body Material | WCB, LCB, WC6, WC9, C5, CF8, CF8M, CF3, CF3M |
| Trim Material | 13Cr, F6a, F316, Stellite Overlay, Customized Trim |
| End Connection | Flanged Ends (ASME B16.5/B16.47), Butt Weld Ends (ASME B16.25) |
| Bonnet Type | Bolted Bonnet / Pressure Seal Bonnet |
| Stem Type | Rising Stem, Outside Screw & Yoke (OS&Y) |
| Disc Type | Plug Type Disc / Needle Type Disc / Throttling Disc |
| Seat Design | Integral Seat / Renewable Seat Ring |
| Operation | Handwheel, Gear Operator, Electric Actuator, Pneumatic Actuator |
| Face to Face Standard | ASME B16.10 |
| Pressure Test Standard | API 598 / ISO 5208 |
| Temperature Range | -196°C to 600°C (Depending on Material Selection) |
| Applicable Media | Steam, Water, Oil, Gas, Chemical Fluids, Process Media |
| Applications | Oil & Gas, Petrochemical, Power Generation, Refinery, Chemical Industry |
Excellent Flow Regulation Performance
Designed with a linear flow control mechanism, Cast Steel Globe Valve provides precise throttling capability and stable flow adjustment, making it ideal for applications requiring accurate media control.
Robust Cast Steel Construction
Manufactured with high-strength cast steel materials such as WCB, WC6, WC9, and CF8M, it offers superior mechanical strength, pressure resistance, and durability in demanding industrial environments.
Reliable Sealing Performance
Precision-machined sealing surfaces and optimized disc-seat design ensure tight shut-off performance, reducing leakage risks and improving operational reliability.
Low Maintenance & Long Service Life
Replaceable seat rings, wear-resistant trim options, and durable internal components help extend valve service life while reducing maintenance frequency.
Wide Industrial Applications
Widely used in oil & gas, refining, chemical processing, power generation, steam systems, and other critical process industries where reliable flow control is required.
